General-purpose coupling for standard phased array probes on flat surfaces is solved by this Phased Array UT Wedge. This reliable wedge establishes the acoustic interface, allowing the phased array unit to accurately steer and focus the ultrasonic beam for efficient NDT. Supplier: Sonatest Ltd.
The X5 Phased Array (PA) UT Wedge is an essential acoustic interface designed to couple X5-series phased array transducers to a test surface, ensuring precise beam refraction and optimised signal coupling for flaw detection.
Acoustic Coupling: Provides a seamless interface between the transducer and the material.
Beam Steering: Refracts the ultrasonic beam at specific angles (variable/specified upon order) for comprehensive inspections.
Versatility: Supports both angled-beam and weld inspections on flat or contoured components.
| Wedge Series: | X5 (Olympus or Similar) |
| Transducer Type: | Phased Array |
| Refracted Angle: | Variable/Specified upon order |
Array Probe Shoe, Beam Steering Accessory
It denotes a wedge family designed for a specific, typically larger or higher-element-count Phased Array probe model.
**Errors and omissions excepted (E&OE)
