XXG-2005 welding test instrument adopts the selected glass X-ray insert carefully. The performance and quality of the insert directly determine the quality of the whole set of XXG-2005 welding test instrument. If the machine is used in the factory, XXG-2005 welding test instrument is more bang for the buck.
IMPROVEMENT OF MATERIAL SELECTION
In addition to the x-ray insert, the core part of the whole XXG-2005 welding test instrument is the high voltage coil. However, after the XXG-2005 welding test instrument are put on the market, there has been a dilemma that high voltage coil quality accidents occur frequently, but XXG-2005 welding test instrument can’t be solved.
In 2006, through the continuous exploration of engineers, we finally found the key to the quality problem of high voltage coil. The uneven diameter of enameled wire used in high voltage coil led to the damage of high voltage coil. After repeated tests for XXG-2005 welding test instrument, the quality problem of high voltage coil was solved after replacing the enameled wire imported from Germany.
SOLID AND DURABLE STRUCTURAL DESIGN
The generator of XXG-2005 welding test instrument is protected by end ring, which is made of nearly 30mm solid steel and wrapped with rubber to prevent vibration and slipping. The end ring prevents damage to the core components in the event of a collision.
XXG-2005 welding test instrument consists of three parts: control console, X-ray generator and low-voltage connecting cables.
Specifications
Panoramic Portable X-ray Flaw Detector (with ceramic X-ray tube)
| Model | Output Voltage (kv) |
Input (kw) |
Focus (mm) |
Beam Angle | Q235 Max. Penetration(mm) |
Weight of Generator(kg) |
Dimension of Generator(mm) |
||
| Cone Target | Flat Target | Cone Target | Flat Target | ||||||
| XXGH-2005 | 100~200 | 2.0 | 1.0×3.5 | 30×360° | 25×360° | 24 | 27 | 31 | 290×615 |
| XXGH-2505 | 150~250 | 2.5 | 1.0×2.4 | 30×360° | 25×360° | 34 | 37 | 35 | 325×705 |
| XXGH-3005 | 170~300 | 3.0 | 1.0×2.3 | 30×360° | 25×360° | 44 | 47 | 43 | 245×715 |
Panoramic Portable X-ray Flaw Detector (with glass X-ray tube)
| Model | Output Voltage (kV) |
Input （kw） |
Focus Size (mm) |
Beam Angle | Q235 Max. Penetration(mm) |
Weight of Generator(kg) |
Dimension of Generator(mm) |
||
| Cone Target | Flat Target | Cone Target | Flat Target | ||||||
| XXH-1005 | 60~100 | 1.2 | 1.0×3.5 | 30×360° | 25×360° | 4 | 6 | 11.1 | 190×530 |
| XXH-1605 | 80~160 | 1.5 | 1.0×3.5 | 30×360° | 25×360° | 12 | 15 | 15 | 225×585 |
| XXH-2005 | 100~200 | 2.0 | 1.0×3.5 | 30×360° | 25×360° | 24 | 27 | 21.5 | 285×665 |
| XXH-2505 | 150~250 | 2.5 | 1.0×2.4 | 30×360° | 25×360° | 34 | 37 | 33.5 | 320×730 |
| XXH-3005 | 170~300 | 3.0 | 1.0×2.3 | 30×360° | 25×360° | 44 | 47 | 40 | 345×830 |
| XXH-3205 | 180~320 | 3.2 | 1.0×5.0 | 30×360° | 25×360° | 45 | 50 | 40 | 345×830 |
| XXH-3505 | 180~350 | 3.4 | 1.0×5.0 | 30×360° | 25×360° | 52 | 55 | 42.6 | 345×830 |
Directional Portable X-ray Flaw Detector (with glass X-ray tube)
| Model | Output Voltage (kV) |
Input (kw) |
Focus Size (mm) |
Beam Angle | Q235 Max. Penetration(mm) |
Weight of Generator(kg) |
Dimension of Generator(mm) |
| XXQ-1005 | 60~100 | 1.2 | 0.8×0.8 | 40° | 8 | 11.1 | 190×530 |
| XXQ-1605 | 80~160 | 1.5 | 0.8×0.8 | 40° | 19 | 15.2 | 225×585 |
| XXQ-2050 | 100~200 | 2.0 | 1.5×1.5 | 40+5° | 30 | 23 | 285×665 |
| XXQ-2505 | 150~250 | 2.5 | 2.0×2.0 | 40+5° | 40 | 35 | 320×730 |
| XXQ-3005 | 170~300 | 3.0 | 2.3×2.3 | 40+5° | 50 | 45.5 | 345×830 |
| XXQ-3205 | 180~320 | 3.2 | 2.5×2.3 | 40+5° | 55 | 45.5 | 345×830 |
| XXQ-3505 | 180~350 | 3.4 | 2.8×3.0 | 40+5° | 60 | 47 | 345×800 |
Directional Portable X-ray Flaw Detector (with ceramic X-ray tube)
| Model | Output Voltage (kV) |
Input （kw） |
Focus Size (mm) |
Beam Angle | Q235 Max. Penetration(mm) |
Weight of Generator(kg) |
Dimension of Generator(mm) |
| XXG-1605 | 80~160 | 1.5 | 0.8×0.8 | 40+5° | 19 | 14.5 | 225×550 |
| XXG-2005 | 100~200 | 2.0 | 2.0×2.0 | 40+5° | 30 | 18 | 285×615 |
| XXG-2505 | 150~250 | 2.5 | 2.0×2.0 | 40+5° | 40 | 30.5 | 320×640 |
| XXG-3005 | 170~300 | 3.0 | 2.5×2.5 | 40+5° | 50 | 36.5 | 345×670 |
| XXG-3505 | 180~350 | 3.5 | 2.5×2.5 | 40+5° | 60 | 38 | 345×670 |
**Errors and omissions excepted (E&OE)
